Machine Features：

・CO2 laser machine 1300x900mm working size.
・EFR F4 CO2 laser tube (Options power: F2,F6,F8; Options brand: Reci, Weiju)
・HIWIN/PMI square guide
・Blade and Honeycomb worktable
・Red dot location
・Ruida 6445G control system
・Blade worktable+Honeycomb worktable

Application:

Acrylic, Plexiglas, Double color plate, Wood, Bamboo, MDF,leather, fabric,Paper, Cardboard, Chipboard, Press Board,Stone, Ceramic, Granite, Marble, Rubber etc

Technical Parameters

Model	STL1309E
Working Area	1300*900mm
Laser Power	80W/100W/120W/150W/180W
Laser Type	CO2 Sealed Laser Tube, 10.6μm
Cooling Type	Water Cooling with Water Chiller
Engraving Speed	0-60000mm/min
Laser Output Control	0-100% Set by Software
Min. Engraving Size	Chinese: 2.0mm*2.0mm; English Letter: 1.0mm*1.0mm
Highest Scanning Precision	2500DPI
Locating Accuracy	≤+0.01mm
Controlling Software	Ruida Control System 6445G
Graphic Format Supported	DST,PLT,BMP,DXF,DWG,AI,LAS,etc
Compatible Software	TAJIMA,CORELDRAW,PHOTOSHOP,AUTOCAD,All type of AUTOCAD Software
Drive System	High-precision Stepper Motor
Auxiliary Equipments	Exhaust Fan and Air Exhaust Pipe
Power Supply	AC110V/220V±10%, 50HZ/60HZ
Working Environment	Temperature: 0-45℃, Humidity5-95%(No Condensate Water)
Option	Up & Down Table, Blade Worktable, Honeycomb Worktable, Rotary Device, Red Dot Position System, Auto-focus Device

Standard Accessories:

Air compressor	Water chiller	Exhaust fan	Tool box

Options

Up-down worktable	Auto focus	Rotary	Wifi
