Machine Features:

・Portable design,small volume,light weight ;
・High speed with galvanometer;
・Low power, consumption power is less than 500w;
・Completely air cooling, low energy;

Application:

・Gold & silver jewellery, sanitary ware, food packing, tobacco products, medicine packing, medical apparatus and instruments, watches&glassware, auto accessories, electronic hardware
・Applicable materials: gold & silver, stainless steel, ceram, plastic, glass, stone, leather, cloth, bamboo and so on
・Auto accessories marking, tobacco products marking, beer bottle marking, ring marking, electronic products marking

Technical Parameters

Model	ST20FD-P
working area	100x100mm/200x200mm/300x300mm
Power	Raycus 20W(Option: Max, IPG)
Marking Depth	≤1.2mm
Marking speed	≤12000mm/s
Min. Line width	0.01mm
Min.Character	0.05mm
Power supply	220V/50Hz
