Technical Parameters
Model |
MU6090UV |
Head type |
3 pcs Epson XP600 |
Working area |
1500px*2250px |
Resolution/Speed |
360x720DPI (4 pass) 11㎡/H360x1080DPI (6 pass) 5.5㎡/H720x720DPI (8 pass) 3㎡/H |
Ink sort |
UV Rigid ink/Gel ink/Soft ink |
Ink system |
Negative-pressure system. |
Maximum media thickness |
500px |
Application Material |
Acrylic, ceramic tile, glass, stainless steel,signboard,phone shell, bottle,MDF, rubber,PVC etc. |
Support file |
PNG,JPG,JPEG,TIFF |
Running system |
Windows7,windows 10 |
RIP software |
Photoprint, ohyx |
Operation environment |
Temp: 20℃-35℃, Humidity: 35%RH-70% RH |
Power supply spec. |
AC110V±10%,AC220V±10%, 50/60±1Hz |
Power |
1200W |
Dimension size |
L1665mm*W1560mm*H720mm |
Packing size |
L1810mm*W1700mm*H890mm |
Net weight |
225kg |
Gross weight |
300kg |
Sample show:
