Vibrating knife automatic cutting machine (also named CNC Flatbed Digital Cutter), which is mainly aimed at the cutting of non-metallic materials, is an essential production equipment in Fabric Furniture industry, advertising industry, automotive interior industry, Gaskets industry, Packaging industry, Leather industry,etc.

The CNC Flatbed Cutter can cut leather materials, fur materials, clothing fabrics, sofa home textile fabrics, composite materials, carpet, and floor mat materials, gaskets, automotive interiors, etc.

When choosing a vibrating knife cutting machine, first check whether your material can be cut. If you are unsure, you can ask the manufacturer.
Choose a high-quality vibrating knife cutting machine
1) Rounded corner size of cutting edge
2) Whether there are dregs on the surface of the incision
3) Verticality and slope of cutting edge

4) Whether the cutting speed is ideal: During the cutting process, the cutting speed has a considerable influence     on the quality of the cut material. The ideal cutting speed will make the cutting surface show a relatively stable line,   and there will be no slag in the lower part of the material.
5) Whether the surface of the material is smooth and smooth after cutting: the selected saw blade is not suitable.   Different sizes of aluminum profiles need different sizes of saw blades to cut, generally pay attention to the thickness   of the saw blade and the number of teeth.
6) Whether there are burrs in the cutting: the irregular parts such as sharp corners and burrs that sometimes   appear in the transition of the work-piece surface during the cutting process are burrs. Burrs directly affect the   dimensional accuracy, shape and position accuracy, and surface roughness of the processed work-piece.
7) Check whether the equipment is complete: After the equipment arrives, when unpacking and accepting, check   whether the random technical data is complete, whether the random accessories, tools, and accessories are   consistent with the list.

8 Important Tips teach you how to maintain the CNC vibrating knife cutting machine?

Vibrating knife cutting machines are now more and more widely used in the processing of flexible materials, but no matter what the machine will have various problems in long-term use, we need to maintain the machine in daily use to extend the service life of the machine. So how to maintain and maintain the vibrating knife cutting machine?


1. The rotating parts of the cutter head should be inspected regularly and irregularly, and the vulnerable parts should be monitored in real-time and changed regularly.
2. The machine should be thoroughly cleaned every week, the horizontal and vertical guide rails, the transmission gear rack should be cleaned, and the lubricating oil should be added.
3. Check whether the horizontal and vertical cutting head is working normally, if it is abnormal, find out the reason in time, and you must contact professional technicians if you can' t solve it by yourself.
4. Check whether all the knives are loose, clean up the rubbish of the cutter head, and keep the position of the rotary knives normal.
5. For the automatic height adjustment device, check whether it is sensitive, and tighten the cutter head several times before cutting to make the air pressure more stable.
6. Check whether the knife belt is too long or too short, and judge whether the distance between the two ends of the damper is the same. If the knife belt is too long or too short, it is not conducive to normal cutting work.
7. Must check and remove dust, clean the machine tool and guide rail dirt every working day,  keeping the machine bed clean, maintenance should be in place, turn off the air source and power supply when off work, and drain the remaining air in the machine tool tube belt at the same time.
8. If you leave the machine for a long time, turn off the power to prevent non-professional operations.

RFQ

Question 1: What materials can be cut by CNC Flatbed Digital Cutting Machine?

Answer: It can cut a variety of materials such as honeycomb board, corrugated paper, plastic corrugated board, gray board paper, white cardboard, film, composite material, leather, cloth, rubber board, pearl cotton, and foam KT board, etc.

Question 2: Will the operation of the Oscillating Knife Cutting Machine be difficult to learn?

Answer: Just input the drawing into the computer and set the corresponding data on the machine. At the same time, if you purchase our machinery and equipment, we will send professional technicians to install, guide, and train you. Under normal circumstances, as long as you know how to use CAD, you can learn it in 2 hours, and then you can complete the independent operation.

Question 3: How long is the warranty period for the vibrating knife cutting equipment?

Answer: The warranty period of the vibrating knife cutting machine is 12 months(not including man-made damage,   consumables: such as counter tops, blades, etc.), lifetime maintenance, free system upgrades; during the warranty period, any quality problems will be replaced or repaired free of charge A maintenance fee is charged; after the warranty period, only the cost of materials and labor costs are charged for the parts that need to be replaced or r   repaired.


Question 4:What is the difference between a vibrating knife cutting machine and a laser cutting machine?

Answer: The vibrating knife cutting machine uses a sharp knife or a round knife to cut through vibration or high-speed rotation. The advantage is that the cutting is clean and neat, the size of the piece is accurate, odorless, and environmentally friendly. The laser cutting machine, the cutting surface is very good and clean. The maintenance of the laser machine is also relatively large. The laser will generate heat after a long time and needs water cooling. After the head burns the fabric, it will leave a yellow mark on many fabrics.
