Product Name  :  Mini CNC Router ST6090

Mini Desktop CNC Router with 4th axis rotary is used for 2D/3D works in advertising industry, arts, crafts, signs, gifts and CNC mold making.

Description
■ Advanced Control System Mach3 or Advanced DSP numerical control system.
■ Large Memory and Perfect Data Transmission Large internal memory of 128M is enough to simultaneously store more than 30 processing files which can be read freely.

Parameter

Model

ST6090

X,Y Working area

600mmx900x100mm

Z height

100mm

Max traveling speed

>50m/min

Reposition precision

0.05mm

Table structure

clamp table device

Command

G code

X,Y,Z structure

Z ball screw, X,Y gear wheel

Compatible software

Ucancam,Artcam,Castmate,Coreldraw

Power(spindle is not included)

1.5KW

Work voltage

220V/1Ph/50Hz

Spindle power

1.5KW water/air cooling(depends on your need)

Spindle rotating speed

0-24000rpm/min

Drive motor

stepper

Application

Arts: can engrave on man-made stone, wood, aluminum, MDF, bamboo, marble, acrylic, double-colored board beautiful drawings and letters.
