Machine frame with high rigidity, after secondary aging fully eliminate internal stresses. Ensure machine accuracy is stable and cutting precision .
It adopts stepping motor and planetary reducer. SBR linear guides ensure the cutting speed and operation of the whole machine.

Machine Features:

Machine frame with high rigidity, after secondary aging fully eliminate internal stresses. Ensure machine  accuracy is stable and cutting precision .
It adopts stepping motor and planetary reducer. SBR linear guides ensure the cutting speed and operation of the whole machine.
Adopt gantry structure, gear transmission, stable cutting.
Use professional CNC cutting software, easy to learn and use greatly improve work efficiency.

Application:

Sheet metal processing, machinery, automotive, shipbuilding, tool processing, petroleum machinery, video machinery, environmental protection equipment, advertising, metal external processing and other processing and manufacturing industries

Technical Parameters:

Model	ST1530P
Working area	1500X3000mm/4000mm
Movement accuracy	0.01mm/step
Moving speed	12000mm/min
Driver	Stepper motor+Leadshine driver(Gantry moveable)
Control system	STARFIRE, STATAI, ShanghaiFangling
Plasma power supply brand	HUAYUAN/Hypertherm
Plasma power	63A,100A,120A,160A,200A,300A,400A
Voltage	380V/3Ph/50Hz
Machine size	3500x4500x1810mm(About)
