Product Name  :  Flame Plasma Cutting Machine ST2070FP

Flame plasma cutting machine for metal

Description

■  Machine frame with high rigidity, after secondary aging fully eliminate internal stresses. Ensure machine  accuracy is stable and cutting precision .

■  It adopts stepping motor and planetary reducer. SBR linear guides ensure the cutting speed and operation of the whole machine.
■  Adopt gantry structure, gear transmission, stable cutting.

■ Use professional CNC cutting software, easy to learn and use greatly improve work efficiency.

■ Flame and Plasma double head cutting mode.

Parameter

Working size

2000x7000mm(machine size customized)

Cutting thickness

0.8-38MM(CS)(Plasma)

8.0-180.0mm (Flame)

 CNC Cutting torch

1 pc

 Up-down range

200mm

 Max speed

12000mm/min

 Working accuracy

±0.3mm

 Flatness error of main and auxiliary rail

±2mm

 Repeat accuracy

±0.3mm

Intersection offset

Straightness of rail

Said straightness of main rail:
≤±0.2mm/10000mm
Said straightness of auxiliary rail:≤±0.3mm/10000mm
Parallelism of longitudinal rail surface and level of the main rail and auxiliary rail: ≤±0.2mm/1000mm





Test pattern: 1000mm×1000mm

Straightness

≤±0.5mm

Roundness

 ≤±0.4mm

Repeat positioning accuracy

≤±0.5mm

Diagonal deviation

≤±0.5mm

Working voltage

380V±10% 50Hz

Total power

25kw

Application

Sheet metal processing, machinery, automotive, shipbuilding, tool processing, petroleum machinery, video machinery, environmental protection equipment, advertising, metal external processing and other processing and manufacturing industries.
