Product Name  :  Plasma Cutting Machine ST1530P

Plasma cutting machine for matal.

Description

■  Machine frame with high rigidity, after secondary aging fully eliminate internal stresses. Ensure machine  accuracy is stable and cutting precision .

■  It adopts stepping motor and planetary reducer. SBR linear guides ensure the cutting speed and operation of the whole machine.
■  Adopt gantry structure, gear transmission, stable cutting.

■ Use professional CNC cutting software, easy to learn and use greatly improve work efficiency.

Parameter

Model

ST1530P

Working area

1500X3000mm/4000mm

Movement accuracy

0.01mm/step

Moving speed

12000mm/min

Driver

Stepper motor+Leadshine driver(Gantry moveable)

Control system

STARFIRE, STATAI, ShanghaiFangling

Plasma power supply brand

HUAYUAN/Hypertherm

Plasma power

63A,100A,120A,160A,200A,300A,400A

Voltage

380V/3Ph/50Hz

Machine size

3500x4500x1810mm(About)

Application

Sheet metal processing, machinery, automotive, shipbuilding, tool processing, petroleum machinery, video machinery, environmental protection equipment, advertising, metal external processing and other processing and manufacturing industries.
