Product Name  :  Dual Process CNC Router ST1325D/T

Sample ATC CNC Router, Double Head ensure improve working working efficiency

Description
■ Industralized welded machine structure, quenching by dragon gatemilling machining high preision, ensure high rigidity and high accuracy.
■ Professional genuine controlling system, our software is compatible with Tpye3, Artcam, Proe, Ug and CAD/CAM software.
■ Z axis with imported Taiwan TBI rolling ball screw and PMI linear raillcan be ensure the machining accuracy
■ Two/three processes, the main spindle can realize the mutual switching, improve work efficiency
■ Y axis with dual motor drive, the drive system of large torque, highload under the processing environment can also be easily


Parameter

Model

ST1325D/T

working area

1300x2500x200mm  Options: 1500x3000x200mm 2000x3000x200mm(Customized)

Spindle power

3.5/4.5/6.0Kw(options)

Guide

HIWIN/PMI(Taiwan)

Control system

PM95A-3L/SYNTEC

Motor and Driver

Stepper Motor and Leadshine Driver /Servo motor and Driver

Max Running speed

40000mm/min

Max working speed

25000mm/min

Working accuracy

±0.05

Repositioning accuracy

±0.02

Power supply

AC380/50HZ

G.W.

1500Kg

Application

* Panel fumiture, solid wood furniture, electronics industry, advertisingdecoration, sound box, speakers musical instruments, soft bag, walls,ect

* Wood, plexiglass, anti-special board, artificial stone, epoxy resin,PVC, ABC, copper and aluminum.
