Product Name  :  ATC CNC Router ST2030ATCL

 ATC CNC Router with Automatic Tool Changer Spindle is used for 2D/3D carving and cutting for woodworking, advertising, mold making and woodcrafts.

Description

■ Heavy duty body.

■  9.0KW Italy HSD air cooling spindle.

■  Automatic Tool Changer Spindle with 10 pieces tools magazine

■  Syntec controlling system.

■  Japan Yaskawa 850W servo motor and drivers.

■ 11KW Delta inverter from Taiwan.

■  Taiwan HIWIN 30 square rails.

■  Japan Omron limited switch.

■  Strong suction Non-oil vacuum pump 5.5KW.

■  Tool sensor.

■  Auto oil-lubrication.


Parameter

Model

ST2030ATCL

Table size

2000mmX3000mmx200mm(Customized)

Control system

Syntec 6MA

Systemic resolution

±0.0025mm

Repositioning resolution

±0.02mm

Max running speed

60m/min

Max cutting speed

30m/min

Tool Magazine

Disc Type 10 tools

Working voltage

380V/3 Phase/50HZ

Spindle

9.0KW HSD air cooling

Spindle Speed

24000r/min

Working air pressure

0.6MPa

Table design

Pure adsorption one zone

Double layer 30mm

Vacuum Pump

5.5KW/160m3/tongyou pump

Including non-return valve and filter

Positioning Cylinder

3

Driving system

Yaskawa 850W servo motor and drivers

Software

Artcam/Type3 (copy)

Weight

2400kg

Application

Panel fumiture, solid wood furniture, electronics industry, advertisingdecoration, sound box, speakers musical instruments, soft bag, walls,ect

Wood, plexiglass, anti-special board, artificial stone, epoxy resin,PVC, ABC, copper and aluminum.
